SPECIFICATION
GENERAL
| Operation Voltage | 14.4V(10.5-16V) |
| Installation Size | 178x152x100MM |
| Net Weight | 1.2kg |
RADIO ITEM
| FM Frequency Range | 87.5-108.0MHZ |
| MW Frequency Range | 522-1620KHZ |
| Usable Sensitivity | 2UV(FM)/80U(AM) (MW) |
BULETOOTH ITEM
| Communication System |
BT 2.1 Version+EDR |
| Output | BT Standard Power 2 Class |
| Max Communication Range | 5m |
| Frequency Band | 2.4GHZ |
| Compatible Bluetooth Protocol | HFP/ HSP/ A2DP/ AVRCP |
USB ITEM
| USB Standard | USB2.0 High Speed |
| File System | FAT 16/32 |
| Max Current | DC 5V-1AD/A |
| Converter | 24BIT |
| Audio/Video Decoder | MPEG1/ PEG2/ MP4/ RMVB/ MP3/ WMA/ JPEG |
TFT SCREEN ITEM
| Size | 6.75 inch |
| Resolution | 800x480 RGB |
| Contrast ratio | 500 |
VIDEO ITEM
| External Video Input System | NTSC/PAL/SECAM |
| External Video Input | 1VP-P/75Q |
AUDIO ITEM
| Max Power: 4X50W | 4X50W |
| Pre-output(V) | 4V/10KΩ |
| Pre-output impedance | ≤600Ω |
| Speakers impedance | 4-8Ω |
| External audio input | 600MV/10KΩ(<l%THD) |
