AudioControl PNW SERIES 2.75″ COMPONENT MIDRANGE SPEAKERS

Regular price
$149.95
Sale price
$149.95
Regular price
Sold out
Unit price
per

AudioControl has over 45 years of experience engineering top-quality audio components. Buckle up and get ready to embark on a wild new auditory adventure with AudioControl’s PNW speakers! Experience the vibrant landscapes of the Pacific Northwest through your music when you combine AudioControl’s legendary amplifiers with the new PNW series of speakers. Trust us, you’ve never heard sound quite like this before. The PNW line features an edge-enhanced steel frame for ultimate structural strength, a black anodized voice coil former for superior heat dissipation, and a linear double-roll surround for precise cone movement. Plus, the rigid poly mica-coated cone optimizes sound reproduction.

Worried about installation? Don’t be! Our speaker sets come with high-quality mounting hardware, so you can enjoy your new sound system hassle-free. The tweeter’s point source design even aligns the output of both drivers perfectly, resulting in better speaker alignment for amazing sound quality.

FEATURES

  • Edge-enhanced steel frame for added structural strength
  • Black anodized voice coil former for superior heat dissipation
  • Linear surround for precision cone movement
  • Complex FEA-designed high-efficiency motor
  • Paper fiber matrix cone with mica coating for optimized sound reproduction
  • Transparent thermal-polymer dust cap for superior fidelity
  • High-quality mounting hardware included

SPECIFICATIONS

Crossover Type                                     Butterworth

DC Resistance (Re).                              2.45 ohms

Filter Type                                             HP

System Frequency (Fs) Response     100-20k Hz

XO Frequency                                      250 Hz

BP Frequency Range                          200-4k Hz

Slope (Octave)                                     -6 dB

Midrange Voice Coil Diameter.        20 mm



IN THE BOX:

PNW-275, Manual, Warranty


DIMENSIONS

  • Overall Dimensions: 3.74 in/ 95 mm
  • Overall Diameter(w/o Metal bracket): 2.83 in / 72 mm
  • Cut Out Diameter: 2.63 in/ 67 mm
  • Mounting Depth: 1.37 in/ 35 mm
  • Mounting Height (w/o Grille): 0.05 in / 1.5 mm
  • Mounting Height (w/ Grille): 0.48 in / 12.4 mm
  • Motor Diameter (w/ Cover): 2.36 in / 60 mm
  • Grille Overall Diameter: 3.42 in / 87 mm
