Product info:
- 3" 2-way speakers
- pulp woofer cone
- 3/4" tweeter
- built-in crossover
- handles up to 85 watts RMS (260 watts peak power)
- frequency range: 230-40,000 Hz
- sensitivity: 83 dB
- Hi-Res Audio Certified
-
- Two 2-way speakers
- Eight 1/2" Screws
- Warranty information
- On-line product registration information
- Important Notice sheet
- Declaration of conformity
- Alpine address information
- Template and specs on box
| General | ||
|---|---|---|
| Speaker Size | 3 | |
| Driver Design | 2-way | |
| Woofer Design | Cone | |
| Woofer Material | Pulp | |
| Woofer Surround | Treated Cloth | |
| Midrange Design | --- | |
| Midrange Material | --- | |
| Tweeter Design | 0.6" Dome | |
| Tweeter Material | Cloth | |
| Super Tweeter Design | --- | |
| Super Tweeter Material | --- | |
| Impedance (Ohms) | 4 | |
| Weather-resistant | No | |
| Grilles Included | No | |
| Parts Warranty | 1 Year | |
| Labor Warranty | 1 Year | |
| Specifications | ||
|---|---|---|
| Sensitivity (1W at 1 meter) | 83 | |
| Sensitivity at 2.83 volts | N/A | |
| Frequency Response | 230 - 40k Hz | |
| Maximum RMS Wattage | 85 | |
| Peak Power Handling (Watts) | 260 | |
| Top-mount Depth (Inches) | 1 1/2 | |
| Bottom-mount Depth (Inches) | N/A | |
| Cutout Diameter (Inches) | 2.4 | |
| Mounting Height (Inches) | 0.371 | |
| Frame Width | 3.008 | |
| Frame Length | 3.008 | |
