Product info:
- marine/powersports mono amplifier
- 160 watts RMS x 1 at 4 ohms (300 watts RMS x 1 at 2 ohms)
- variable low-pass filter (35-300 Hz, 12 dB/octave)
- variable subsonic filter (20-40 Hz)
- bass boost (0-12 db at 43 Hz)
- Class D amplifier design with NextD™ switching amp technology
- IPX7 water-resistance rating
- corrosion-resistant cast aluminum chassis
Other Features:
- preamp and speaker-level inputs (speaker wire to RCA adapter required for speaker-level input)
- fuse rating: 35A x 1
- 8-gauge power and ground leads and a 30-amp fuse recommended — wiring and hardware not included with amplifier
- 8-11/16"W x 1-13/16"H x 3-1/8"D
- warranty: 2 years
- MFR # 010-03324-00
- Item # 13698406
-
JL Audio MX300/1 owner's manual
- Mono marine amplifier with 12" power/signal pigtails
- 35A ATO fuse
- 4 Self-tapping screws (1" length)
- Owner's Manual
| Performance | ||
|---|---|---|
|
|
160 x 1 |
|
|
|
N/A | |
|
|
300 x 1 | |
| Power at 1 Ohm (Watts x Channels) | --- | |
|
|
N/A | |
|
|
N/A | |
|
|
2 | |
|
|
20-12k Hz | |
|
|
1% | |
|
|
85 dB | |
|
|
14.4v | |
| Features | ||
|---|---|---|
|
|
D | |
|
|
No | |
|
|
Optional | |
|
|
40-400 Hz | |
|
|
24 dB/octave | |
|
|
N/A | |
|
|
N/A | |
|
|
0-12 dB | |
|
|
43 Hz | |
|
|
No | |
|
|
35 | |
|
|
Yes | |
|
|
No | |
|
|
8-11/16 | |
|
|
1-13/16 | |
|
|
3-1/8 | |
|
|
2 Years | |
|
|
2 Years | |
