Product info:
- 4-channel amplifier
- 50 watts RMS x 4 at 4 ohms (70 watts RMS x 4 at 2 ohms)
- 140 watts RMS x 2 bridged at 4 ohms (4-ohm stable bridged)
- variable low- and high-pass filters (35-300 Hz, 12 dB/octave)
- Class D amplifier design with NextD™ switching amp technology
- IPX7 water-resistance rating
- corrosion-resistant cast aluminum chassis
Other Features:
- preamp and speaker-level inputs (speaker wire to RCA adapter required for speaker-level input)
- fuse rating: 35A x 1
- 8-gauge power and ground leads recommended — wiring and hardware not included with amplifier
- 8-11/16"W x 1-13/16"H x 3-1/8"D
- warranty: 2 years
- MFR # 010-03105-00
- Item # 13698405
-
JL Audio MX280/4 owner's manual
- 4-Channel marine amplifier with 12" power/signal pigtails (with in-line fuse holder and 35A ATO fuse installed)
- Spare 35A ATO fuse
- 4 Self-tapping screws (1" length)
- Owner's Manual
| Performance | ||
|---|---|---|
|
|
50 x 4 |
|
|
|
N/A | |
|
|
70 x 4 | |
| Power at 1 Ohm (Watts x Channels) | --- | |
|
|
140 x 2 | |
|
|
4 | |
|
|
2 | |
|
|
20-20k Hz | |
|
|
--- | |
|
|
89 dB | |
|
|
14.4v | |
| Features | ||
|---|---|---|
|
|
D | |
|
|
No | |
|
|
No | |
|
|
35-300 Hz | |
|
|
12 dB/octave | |
|
|
35-300 Hz | |
|
|
12 dB/octave | |
|
|
No | |
|
|
N/A | |
|
|
No | |
|
|
35 | |
|
|
Yes | |
|
|
No | |
|
|
8-11/16 | |
|
|
1-13/16 | |
|
|
3-1/8 | |
|
|
2 Years | |
|
|
2 Years | |
