Product info:
- mono subwoofer amplifier
- 750 watts RMS x 1 at 4 ohms
- 1500 watts RMS x 1 at 2 ohms
- 1500 watts RMS x 1 at 1 ohm
- Class D amplifier design with NextD™ switching amp technology
- differential-balanced inputs help eliminate noise
- variable low-pass filter (50-500 Hz, 12 dB/octave)
- variable bass boost (0-12 dB at 45 Hz)
- LED clip light helps set gain
Other Features:
- blue LED accent lighting
- optional wired remote level control
- preamp inputs and outputs
- speaker-level inputs (speaker wire to RCA adapter required)
- wiring, fuse, and hardware not included with amplifier
- 2-gauge power and ground leads and a 150-amp fuse recommended
- 18-1/16"W x 2-3/16"H x 7"D
- warranty: 2 years
- MFR # 010-03333-00
- Item # 13698643
-
JL Audio RD1500/1 owner's manual
- Mono subwoofer amplifier
- JL Audio badge
- 3mm Allen wrench
- 2.5mm Allen wrench
- Owner's manual
| Performance | ||
|---|---|---|
|
|
750 x 1 |
|
|
|
N/A | |
|
|
1500 x 1 | |
| Power at 1 Ohm (Watts x Channels) | 1500 x 1 | |
|
|
N/A | |
|
|
N/A | |
|
|
1 | |
|
|
7-500 Hz | |
|
|
1% | |
|
|
50 dB | |
|
|
14.4v | |
| Features | ||
|---|---|---|
|
|
D | |
|
|
No | |
|
|
Optional | |
|
|
50-500 Hz | |
|
|
12 dB/octave | |
|
|
N/A | |
|
|
N/A | |
|
|
0-12 dB | |
|
|
45 Hz | |
|
|
No | |
|
|
150 | |
|
|
Yes | |
|
|
2 | |
|
|
18-1/16 | |
|
|
2-3/16 | |
|
|
8 | |
|
|
2 Years | |
|
|
2 Years | |
